Home Products-Terminal Blocks Breakout Board Adapter

DB26 Female Header Breakout Board Terminal Block Connector Electronics-Salon Breakout Board

DB26 Female Header Breakout Board Terminal Block Connector Electronics-Salon Breakout Board

DB26 Female Header Breakout Board Terminal Block Connector Electronics-Salon Breakout Board
DB26 Female Header Breakout Board Terminal Block Connector Electronics-Salon Breakout Board DB26 Female Header Breakout Board Terminal Block Connector Electronics-Salon Breakout Board DB26 Female Header Breakout Board Terminal Block Connector Electronics-Salon Breakout Board

Large Image :  DB26 Female Header Breakout Board Terminal Block Connector Electronics-Salon Breakout Board Get Best Price

Product Details:
Place of Origin: Shenzhen
Brand Name: starpai
Certification: UL,Rohs
Model Number: QXDB-DB26M
Payment & Shipping Terms:
Minimum Order Quantity: 100 sets
Price: US 18per sets
Packaging Details: bag
Delivery Time: 20-25 work days
Payment Terms: T/T, MoneyGram, Western Union
Supply Ability: 5000 sets per month
Detailed Product Description
DUSB: DB26 Terminal Block Pitch: 3.81mm
Rated Voltage: 60V Rated Current: 1A

Product description

DB26 Female Header Breakout Board Terminal Block Connector Electronics-Salon Breakout Board 0

DIN Rail Mount DB26HD(High Density) Female Interface Module.

DB26 female header connector, pitch 2.29mm
Pitch 3.81mm/0.15" screw terminal block.
High quality DIN rail mount carrier, can support width 35mm / 32mm / 15mm rail, and the carrier can be taken apart for panel mount use.
Dimensions: 88mm x85mm x 53mm(W x L x H).
100% new, never used.

Rated voltage: 60V.
Rated current: 1A / per pin.
Operating Temperature: -20ºC to 50ºC

Terminal block specifications:
Wire range - 26-16AWG.
Strip length - 5mm.
Screws - M2,steel,Cr3+ Zn plated.
Torque - 0.2Nm (1.7Lb-In.).
Pin header and Cage - Brass.

Other D-SUB modules (DB9 15 15HD 25 26HD 37 44HD 50 62HD 78HD), please visit our website.
