Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203

Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203

Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203
Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203 Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203 Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203 Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203 Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203

Large Image :  Wire protector terminal pin dip 90°| Pitch: 5.00mm,5.08mm | Part No.511-5.00 / 5.08-203 Get Best Price

Product Details:
Place of Origin: Shenzhen,China
Brand Name: STARPAI
Certification: EC,UL,Rohs
Model Number: 511-5.00/5.08-203
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: 0.1usd
Packaging Details: Packing
Delivery Time: 25 days after 100% T/T payment
Payment Terms: T/T, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000K/pcs
Detailed Product Description



Features of terminal block connectors:

Special wire protector design to ensure reliable wire clamping

Be capable of clamping a wide range of wire diameters

The Male connector of plug using a twin leaf phosphor bronze contact mates with the female socket

The Female socket is mounted and soldered to the PCB

Good for insertion & withdrawal

UL 94V-0 grade fire retardant engineering plastic used for the housing

Product name 5.0/5.08mm pitch 300V PCB screw terminal blocks,Euro electrical brass terminal block connectors for pcb
Pitch 5.0/5.08mm
Current 15A
Voltage 300V
Withstanding voltage AC2000V/1min
Torque 0.4 Nm (3.5 lb.in)
Strip length 6-7mm




-------------------------------------------
