Home Products-Screw Type Din-Rail Terminal Block

Din Rail Pluggable Terminal Block socket with 5.08mm Pin Spacing socket arrage:24-12 AWG

Din Rail Pluggable Terminal Block socket with 5.08mm Pin Spacing socket arrage:24-12 AWG

Din Rail Pluggable Terminal Block socket with 5.08mm Pin Spacing socket arrage:24-12 AWG
Din Rail Pluggable Terminal Block socket with 5.08mm Pin Spacing socket arrage:24-12 AWG Din Rail Pluggable Terminal Block socket with 5.08mm Pin Spacing socket arrage:24-12 AWG

Large Image :  Din Rail Pluggable Terminal Block socket with 5.08mm Pin Spacing socket arrage:24-12 AWG Get Best Price

Product Details:
Place of Origin: Shenzhen,China
Brand Name: STARPAI
Certification: EC,UL,Rohs
Model Number: DTB 5.08-203-3
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: 4.86 USD/PCS
Packaging Details: Packing
Delivery Time: 25 days after 100% T/T payment
Payment Terms: T/T, L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability: 100000K/pcs
Detailed Product Description
Material: PA And Cu Rated Voltage/current: 300V 15A
Poles: 02-24 Poles Pitch: 5.08mm
Color: Green

Materials and specifications
Plastic parts: PA66 UL94V - 0
Terminal: brass, Tin plating
Spring: steel

performance

Pitch:5.08mm
Rated voltage/current: 300 V/ 15A
Temperature: - 40 ℃ ~ + 105 ℃
The withstand voltage: AC1500V/Min
Insulation resistance: 500 mΩ / DC500V

Wire range:24-12 AWG



Din Rail Pluggable Terminal Block socket with 5.08mm Pin Spacing socket arrage:24-12 AWG 0
