Plug-Terminal Block Head vertical connect wire Pitch:5.08mm / 0.2 in

Plug-Terminal Block Head vertical connect wire Pitch:5.08mm / 0.2 in
Plug-Terminal Block Head vertical connect wire Pitch:5.08mm / 0.2 in Plug-Terminal Block Head vertical connect wire Pitch:5.08mm / 0.2 in Plug-Terminal Block Head vertical connect wire Pitch:5.08mm / 0.2 in

Large Image :  Plug-Terminal Block Head vertical connect wire Pitch:5.08mm / 0.2 in Get Best Price

Product Details:
Place of Origin: Shenzhen
Brand Name: srarpai
Certification: UL,CUL,Rohs
Model Number: 404-5.08/5.0-102-3
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: US 0.1 - 1.0 US
Packaging Details: Bag
Delivery Time: 15- 25 work days
Payment Terms: T/T
Supply Ability: 1000K pcs per month
Contact Now
Detailed Product Description
Material: Green,Orange,Black,Blue Or By Customer Pitch: 5.00/5.08mm
Rated Voltage: 300V Rated Current: 10A
Wire Range: 24-12AWG Poles Range: 2-24 Poles

Detailed Product Description
Plug-Terminal Block Head vertical connect wire Pitch:5.08mm / 0.2 in 0

Plug-Terminal Block Head vertical connect wire Pitch:5.08mm / 0.2 in 1
Detailed
Pitch: 5.00/5.08mm
Poles: 2-24 Pin
Material: Case PA66,UL94 V-0
Contact Brass,Ni plated
Protector Phosphor bronze,Tin Plated
Screw M3,C1018 steel,Zinc plated

Electrical
Voltage 250 V
Current rating 10A
Electrical Withstanding AC2500V,1minute
Isolation resistance DC500V 500MΩ
Wire range 24-12AWG
Max Torque 4.0kgf.cm

Mechanical
Operation temperature - 33℃～+105℃
Strip length 7-8mm
